BDS Suspension 1-2 Inch Leveling Kit Performance Spring 1" for 17-19, 2" for 20-26 (2017-2026 Powerstroke 4WD)
By ordering the BDS Suspension 1-2 Inch Leveling Kit Performance Spring 1" for 17-19, 2" for 20-26 (2017-2026 Powerstroke 4WD) you will earn 630 DIESEL DOLLARS in your SDS Fuel Tank!
|Diesel Dollars is Southern Diesel Supply's Loyalty Program. Purchasing with Us Earns you 2% Cash Back to use for future buys!|
Description
**You will be contacted and charged separately about shipping cost.**
Simply level out your Ford F250 and F350 Super Duty truck to the next level with this performance spring 2-inch leveling kit from BDS Suspension. Designed to improve stance, performance, and capability, this kit includes everything necessary to set your truck up right with clearance for up to 35 inch Tires.
Up front the lift kit includes dual rate Pro-Ride coil springs, track bar relocation bracket for steering correction, and alignment cams. This kit is rounded out with your choice of NX2 twin tube gas or FOX 2.0 Performance Series monotube Internal Floating Piston shocks to further dial in the comfort and control of your F250/F350.
Pro-Ride Coil Springs
A pair of full-length Pro-Ride coil springs are supplied to provide the correct lift height and smooth, predictable ride across various terrains. These dual rate springs utilize a softer intial spring rate over factory for improved on-road comfort, while also using a higher secondary spring rate to provide stability and performance in harsh terrains.
- Front Lift Method: Coil Spring
- Rear Lift Method: Stock
- Shocks Included: Yes
- Front Lift Height: 2 Inch
- Rear Lift Height: 0 Inch
- 2017-2019 models net 1 Inchof lift height; requires an additional 1 Inchcoil spring spacer to sit level.
- 2020-2024 models net 2 Inch.
- Kit designed for diesel models; Gas models will achieve approx. 1/2 Inch more ride height
- Easy, 100 percent Bolt-on installation
- Pro-Ride dual rate coil springs ride smooth through any terrain
- Heavy duty track bar relocation bracket designed to recenter the front axle
- Standard NX2 Nitro shocks with vehicle-specific valving for better control
- Upgrade to FOX 2.0 Performance Series shocks for maximum performance on and off-road
FOX 2.0 Performance Series
- 2-inch Impact extruded aluminum body
- Internal floating piston (Internal Floating Piston) monotube design
- CNC machined 6061-T6 aluminum mounting ends
- Massive 5/8-inch hard chrome plated heat-treated alloy steel shaft
- Race-developed high-flow piston design
- Application-specific valving to maximize performance
- Long-lasting clear anodized finish
Tire Size: 35 x 12.5 Tire Size 2: 35 x 12.5 Wheel Diameter: 18 x 9 Wheel Diameter 2: 20 x 9 Back Spacing: 4.5/4.5
Kit Components:
- Includes one BDS013205, 2017-2019 1 Inch/2020-2023 2 Inch F250/350 Front Box Kit, UPC Code 658848613120
- Includes one BDS033202, 2017-2019 1 Inch/2020-2023 2 Inch F250/F350 Front Coil Spring Kit, UPC Code 658848616473
- Includes two FOX98224710, Fox 2.0 Shock 23.27 x 14.65 x 2- S50/EB1
- Includes two FOX98224717, Fox 2.0 Shock 30.05 x 18.45 x 2- EB1/EB1
